Revision History: (Included for reference)
Date: April 22, 1998
G11: Checksum: E418 (G) E018 (N)
Changes from revision 1.7:
Fixed a problem where the drop difficulty (adjustment
“DROP SEQUENCE NUM.” was being used at game start instead
of each player’s first ball. This resulted in the adjustment
only working for the very first player up in a multi-player game.
Date: November 25, 1996
G11: Checksum: D617
Changes from revision 1.6:
Removed sound tests 13-17 for German sound ROMs.
The kickback pauses the game timer during kicks.
Explode, Cyberdog, and Alarm mode timers now pause during
Enhanced the “Bribe Guard” rules using donuts.
Date: September 13, 1996
G11: Checksum: 6016
Changes from revision 1.5:
Changed some strings for German games.
Date: August 2, 1996
G11: Checksum: 9815
Changes from revision 1.4:
Adjustment A.2.22 (MAGIC TOK. ACCEPT) has been modified to
allow the token to be used for “BUY-IN”. The “BUY-IN” setting
allows tokens won during a game to be used to extend the
Changes made to reset the board game if the game is tilted
while playing the board game.
The audit for matches now properly chalks an audit for
match when the match gives a token.
Date: June 11, 1996
G11: Checksum: FC14
Changes from revision 1.2:
Added support for more printers through the optional serial port.
Completed Spanish translations.
Made the factory default for French have the
maximum tokens per player set to 1.
Added the adjustment A.1.14: ‘REPLAY AWARD’ which allows the
operator to turn off replays.
Attract mode now shows the number of tokens available
in the vault jackpot.
Added 2 new feature adjustments:
– LOCK FOR BANK – This adjustment determines whether the
player must lock a ball before playing the board game.
YES: player must lock at least 1 ball before break in
NO: player must only complete drop banks to break in
Default is YES
– START BANK LIT – This adjustment determines whether the
bank is lit for a break in at game start.
Default is NO
Implemented adjustment A.1.16 which allows match to award
credits or tokens.**
**NOTE: Tokens paid out by Match are NOT included
in A.2.21: ‘TOKEN PAYOUT %’. The match percentage is
governed by adjustment A.1.19: ‘MATCH FEATURE’.
When match is set to token in the ‘N’ version of the
software, the match percentage is fixed at 5%.
Fixed a condition in token multiball which could allow
a player to win more tokens than were available in the
Changed logic so that if the token tubes run out or
become jammed in the middle of token multiball, the
player will get points as a substitution.
Changed the minimum allowed value for adjustment A.2.7:
“TIMER STARTS AT” to 15 minutes.
Fixed a problem where under some conditions, the game would
not allow you to change adjustments.
Date: May 13, 1996
G11: Checksum: FF12
Changes from revision 1.1:
Put in support for new German speech. This requires version 2.3
of the German sound ROMs.
Fixed the screens for the tests of the auxiliary lamps.
Date: May 6, 1996
G11: Checksum: 2111
Changes from revision 1.0:
Added French language text translations.
When a magic token is set to give the player a credit, the
free-play percentage audit is now chalked when the token
Added an adjustment to make the knob-numbers random during
spins. Some players were able to pick their numbers entirely
too often, which made the odds of success much too high.
Choices are YES (random) and NO (sequential). This adjustment
factory sets to YES (random).
Changed the replay system so that scores accumulated during
Assault on the Vault are not counted in the auto replay
Fixed message and choreography when a token is won from the
gift lady or ‘?’ game. In version 1.0, these cases would
say “free credit” instead of “free token” , and wouldn’t
wait long enough for the token to be released.
Patched a bug in the lamp effect system that would sometimes
cause the game to crash when the assault mode jackpot shot
New rule added for ‘call guard’. This is now a random
chance of the guard letting you into the board game for
Fixed the coil test for the ramp – it got broken in version
1.0 when the duty cycle was increased.
Removed the “guards moved” from bonus and status.
Added a basic top trough test.
Filled in the sound test table.
Hid all token adjustments when the tokens are turned off.
Disabled token-input when the tokens are turned off.
Added “number of board games played” audits: these audits
tell how many players played the board game exactly 1,2,3
or 4 times in the same game.
Collecting the “assault from all sides” award in assault
mode now awards vault letters.
Date: April 29, 1996
G11: Checksum: 7910
Changes from revision 0.91:
Initial release to production.
Ordered Lamp Test implemented
Conditions of the optos at powerup are tested
to help determine if the 12V supply is not working.
Added the continue/quit choices back to the board game.
Defaults: On for GERMANY, off for USA.
Increased the duty cycle of the ramp divertor slightly
to compensate for divertors that were not able to hold the
mechanism in when flash bulbs were firing.
Changed the token spitter process(es) to not log audits
for vended tokens during test mode. During test,
error cases are cleared out, but no feature audits
Added more specific token errors to the user-report for
each particular side – empty and consecutive misses.
Also, made sure not to report token system errors if the
tokens are turned off via the feature adjustment.
Added more robust code to the token releasing code
to help with broken switch(es), and to help the operator
better diagnose what the game thinks is wrong.
Reworked logic when you reach the vault to handle cases where
tokens are allowed but the mech is marked jammed. The
player now will get a REPLAY if permissible, with a magic
credit powerup, if the feature has been enabled.
Changed the sequencing of the REPLAY effect if you win
one as you reach the vault.
The “magic token accept timers” are totally functional.
Both flippers or the start button will speed up the
timer. Credit button presses while the timer is running
will be eaten. Once the last token is inserted, a display
effect of the “credits” flavor is launched to tell the
player that their last token was credited.
Implemented a family mode adjustment. If the adjustment
is set, the cop will not get shot at during the beginning
of assault mode.
The lamp effect for a whole drop bank shot during tnt
multiball no longer uses the wheel lights. This is so
players can see that the mode is adding time.
Left kicker now spots a drop target if an entrance is not lit.
Player’s wheel position is now restored each ball during multi
SOUND REVISION HISTORY (Included for reference):
This revision eliminates a ‘buzzing’ sound that is occasionally emitted from some games.
