Revision History (Included for reference):

*************************************************************************
* *
* STERN PINBALL, INC. *
* (C) COPYRIGHT 1999-2004, STERN PINBALL, INC. *
* *
*************************************************************************

Harley Davidson

Initial Release

September 7, 1999

ROM Size Board Location Checksum Version File Name
——————————————————————–

Game ROM 1M U210 $07FF 1.00 harcpu.100
Display 4M Rom 0 $EFBA 1.00 hddispa.100
Sound 512k U7 $F4FF 1.00 hdsnd.u7
Voice 1 8M U17 $CD26 1.00 hdvc1.u17
Voice 2 8M U21 $9396 1.00 hdvc2.u21
Voice 3 8M U36 $FB72 1.00 hdvc3.u36
Voice 4 4M U37 $6100 1.00 hdvc4.u37

******************************************

September 20, 1999 2nd release. VERSION 1.01

ROM Size Board Location Checksum Version File Name
——————————————————————–
Game ROM 1M U210 $AAFF 1.01 harcpu.101
Game ROM 1M U210 $AAFF 1.01 harcpuk.101
Display 4M Rom 0 $F594 1.01 hddispa.101
Display 4M Rom 0 $01B8 1.01 hddispg.101
Display 4M Rom 0 $B2E8 1.01 hddispf.101
Display 4M Rom 0 $EC60 1.01 hddisps.101
Display 4M Rom 0 $7366 1.01 hddispi.101

* mystery awards displayed the wrong awards

* many new sounds and speech added

* extraball & special hurry-ups added

* fixed advance gears in SAVE_BANKS

* added light show to speedometer jp

* patch hurry-up award an extra 1M points

* redlite MB jackpot ready display the wrong amount

* made getting to Milwaukee easier

* Patch hurry-up started and collected on the same shot bug

* Patch Hurry active during Video mode bug

******************************************

September 30, 1999 3rd release. VERSION 1.02

ROM Size Board Location Checksum Version File Name
——————————————————————–
Game ROM 1M U210 $3EFF 1.02 harcpu.102
Game ROM 1M U210 $3EFF 1.02 harcpuk.102
Display 4M Rom 0 $F595 1.02 hddispa.102
Display 4M Rom 0 $0504 1.02 hddispg.102
Display 4M Rom 0 $B2F9 1.02 hddispf.102
Display 4M Rom 0 $F3CD 1.02 hddisps.102
Display 4M Rom 0 $71D1 1.02 hddispi.102

* Operator alert messages for motorcycle & scoop are incorrect

* 16 (instead of 25) cities for Milwaukee (i.e. Milwaukee is the 16th city)

* no *city speak* during final mode

* regular pops show distance to city

* letters of LIVE-2-RIDE don’t correspond after MBALL

* 20M Super Jackpot via RedLiteMB (instead of 10M)

* allow enough time for a player to score a perfect 4M on patch hurry-up

* bozo extra ball lit at 30M on last ball

* higher jackpot scores for Milwaukee

******************************************

October 1, 1999 4th release. VERSION 1.03

ROM Size Board Location Checksum Version File Name
——————————————————————–
Game ROM 1M U210 $3EFF 1.03 harcpu.103
Game ROM 1M U210 $3EFF 1.03 harcpuk.103
Display 4M Rom 0 $F591 1.03 hddispa.103
Display 4M Rom 0 $0500 1.03 hddispg.103
Display 4M Rom 0 $B2F5 1.03 hddispf.103
Display 4M Rom 0 $F3C9 1.03 hddisps.103
Display 4M Rom 0 $71CD 1.03 hddispi.103

* 20M Super Jackpot via RedLiteMB (instead of 10M) display bug

******************************************

Display 4M Rom 0 $FC7C 1.04 hddispa.104
Display 4M Rom 0 $09ED 1.04 hddispg.104
Display 4M Rom 0 $B8E1 1.04 hddispf.104
Display 4M Rom 0 $F9B5 1.04 hddisps.104
Display 4M Rom 0 $79B7 1.04 hddispi.104

******************************************

October 28, 2002 5th release. VERSION 1.05

ROM Size Board Location Checksum Version File Name
——————————————————————–
Game ROM 1M U210 $18FF 1.05 harcpu.105
Display 4M Rom 0 $B594 1.05 hddispa.105
Display 4M Rom 0 $CCFB 1.05 hddispg.105
Display 4M Rom 0 $6CFE 1.05 hddispf.105
Display 4M Rom 0 $B8C7 1.05 hddisps.105
Display 4M Rom 0 $3DC4 1.05 hddispi.105

* removed invalid switch information from tech alert

* removed references to Sega Pinball, Inc.

* added Stern Pinball Logo

******************************************

October 31, 2002 6th release. VERSION 1.06

ROM Size Board Location Checksum Version File Name
——————————————————————–
Game ROM 1M U210 $23FF 1.06 harcpu.106

* dev. sound test replaced with standard sound test

******************************************

July 18, 2003

ROM Size Board Location Checksum Version File Name
——————————————————————–
Game ROM 1M U210 $25FF 1.07 harcpu.107

* auto replay % removed, new factory default volume (for interim boards)

******************************************

July 22, 2003

ROM Size Board Location Checksum Version File Name
——————————————————————–
Game ROM 1M U210 $23FF 1.08 harcpu.108

* ignore bike switches in diag for .5 seconds when bike motor is initially
turned on



******************************************

October 25, 2004

ROM Size Board Location Checksum Version File Name
——————————————————————–
Game ROM 1M U210 $22FF 3.00 harcpu.300
Display 4M Rom 0 $B596 3.00 hddispa.300
Display 4M Rom 0 $CCFD 3.00 hddispg.300
Display 4M Rom 0 $6D00 3.00 hddispf.300
Display 4M Rom 0 $B8C9 3.00 hddispl.300
Display 4M Rom 0 $3DC6 3.00 hddispi.300

* 3rd Edition



******************************************

November 22, 2004

ROM Size Board Location Checksum Version File Name
——————————————————————–
Game ROM 1M U210 $23FF 3.01 harcpu.301

* removed headlight from lightshows

June 29, 2005

ROM Size Board Location Checksum Version File Name
——————————————————————–
Game ROM 1M U210 $1CFF 4.00 harcpu.400
Display 4M Rom 0 $B3A8 4.00 hddispa.400
Display 4M Rom 0 $CB30 4.00 hddispg.400
Display 4M Rom 0 $681B 4.00 hddispf.400
Display 4M Rom 0 $B7DF 4.00 hddispl.400
Display 4M Rom 0 $409F 4.00 hddispi.400

* added Belgium/Holland Euro coinage settings

* removed phone numbers from portals

* added auto replay %



Disclaimer:
There is no charge or cost assessed for the software itself contained on the chips. Software remains property of the respective author / manufacturer / copyright holder, who has made the software freely available to the pubic for the purpose of repairing your own machine. We do not sell or claim ownership to ANY software. This listing is ONLY for the cost of the chips themselves, and the service of programming them for you in a format that can be installed in your machine.

Weight .25 lbs
Stern Options

1ST GEN CPU v1.03 / DISP v1.04 Set [U210, ROM0], 2ND GEN CPU v1.08 / DISP v1.05 Set [U210, ROM0], 3RD GEN CPU v4.00 / DISP v4.00 Set [U210, ROM0], Sound ROM [U7], Sound ROM [U17], Sound ROM [U21], Sound ROM [U36], Sound ROM [U37]
